The full name of
PCBA is Printed Circuit Board Aseembly, which means that the entire process of the PCB blank board passing through the
SMT upper part and then through the DIP plug-in is called PCBA for short.Printed circuit board, also known as printed circuit board.Printed circuit board, often referred to as PCB (Printed circuit board), is an important electronic component, a support for electronic components, and a provider of circuit connections for electronic components. Because it is made using electronic printing technology, it is called a "printed" circuit board.
Our SMT assembly capabilities include:
- Manufacturing process: line width, line spacing (2mil), layering.
- Delivery method: sample/batch
- Quality: 1 year quality guarantee.
- Various surface treatments: NiPdAu/Au-Thick (200U”)
- Production lines: 2 sample production lines, 4 mass production lines
- UL certification, RoHs, TS16949, ISO14001
- Strict testing procedures are followed to ensure high quality and fast delivery
Contact：Mikro
Email: Mikro@dicksoncircuit.com
Tel: +86 137 135 41332
WhatsApp: +86 13713541332
Skype:live:.cid.e4c8b7014891008c
https://join.skype.com/invite/yrIQSCng8det
Wechat:+86 13713541332
SMT processing:
SMT line number:8 high-speed SMT patch supporting production lines
Testing equipment:SPI detection of solder paste thickness.100%AOI scanning full inspetion,
FQC full inspection.function test,X-RAY detector, first article tester, ICT tester, BGA rework station
Placement speed: CHIP component placement speed (under optimal conditions) 0.036 S/piece
The smallest package that can be attached is: 0201, the accuracy can reach ±0.04mm
Minimum device accuracy: PLCC, QFP, BGA, CSP and other devices can be mounted, with a pin spacing of ±0.04mm
IC patch accuracy: It has a high level of mounting ultra-thin PCB boards, flexible PCB boards, golden fingers, etc.
Can mount/insert/mix TFT display driver boards, mobile phone motherboards, battery protection circuits and other difficult products
Printed circuit board production and assembly services:
- Professional engineers watching
- The solder paste is made from reliable Sn96.5Ag3Cu0.5 silver-containing solder paste.
- A variety of testing equipment: SPI solder paste thickness test, 100% AOI scanning full test, FQC full test, functional test.
- BGA is X-ray tested throughout the production process and meets ISO requirements.
Dickson Circuit Co.,Ltd has a 17 year history of producing high quality PCBA.
We cooperates with many well-known companies such as Samsung, Osram, Philips, and China Southern Power Grid.
Just give me a Gerber file, and I will definitely give you a satisfactory product.
If you are interested, please feel free to contact me at any time.
